Electrical Features | Rated power | 82KW/142KW/182KW |
Input voltage | 3-phase 260-530Vac |
Input frequency | 50Hz/60Hz |
Measuring accuracy | Level 0.5 |
Output voltage | 150~750Vdc (Optional:150-1000V) |
Efficiency | ≥95% |
Power factor | ≥0.99 |
Output Current | |
Functional Features | User Interface | Emergency stop button, LED indicator, card swiping, touch screen |
Charging standards | IEC 61851-1/IEC 61851-23/-24:2014/ISO15118-1-2013 ISO15118-2-2014/ISO 15118-3:2015/IEC 62196-1-2014 IEC 62196-3-2014/DIN 70121-2014 |
Communication | Internet Interface | Ethernet,WIFI,4G |
OCPP | OCPP 1.6J |
Working environment | Working latitude | <2000m |
Working temperature | -30 ° C ~ +70 ° C (Output degraded above 50° C ) |
Working humidity | 5% ~ 95% without condensation |
Protection level | IP55/IK10 |
Cooling | Forced-air cooling |
MTBF | 100,000 hours |
Safety standards | EN 61851-1-2001; EN 61851-21-2001; EN61851-22-2001 |
Security design | Over/under voltage protection, overload protection, current leakage protection, grounding protection, over temp protection, lightening surge protection |
1. Have high voltage charging gun of European standard, American
standard and Japanese standard. It can generate different charging
configures according to customers’ requirements.
2. Modular design, adapt to customers’ needs.
3. OCPP communication protocol
4. Have open, shareable data service platform and management
platform (cloud platform)
5. Have protection functions such as input under voltage, input
overvoltage, output short-circuit, output overvoltage, output
overcurrent, battery reverse connection, insulation detection,
communication failure, etc.
6. Have an external running indication, which can display the
real-time status.
7. Wide range of AC output voltage, high suitability of utility
grid, three phase three wire input without null line in the
rectifier unit.
8. Has the function of protocol self-recognition, can realize the
charging for electric vehicles without limitation of brand.
9. Compatible with coaches and cars charging function.
10. One pile can charge multiple vehicles, and take turns to charge
automatically by applying automatic switch function between
charging according to the charging power and according to time. It
can automatically judge whether the battery is full, one charging
pile can meet at least five vehicles charging service task one
night.
11. Emergency protection and alarming function, including over
voltage, under voltage, over current, over temperature, phase
missing, output short-circuit, leakage protection and so on.
12. Charging protection function, the charging process will suspend
immediately when BMS communication faults, disconnection, over
temperature and over voltage occur.
13. Emergency stop function, the charging process can be suspended
immediately by emergency stop switch.
14. Has multiple communication interface such as CAN,RS485/
RS232,Ethernet, 3G wireless networks, which can achieve
communication among AC input unit, charging module and DC charging
terminal interface, obtain electric vehicle battery system
parameters and battery operation parameters during charging
process.
15. Has insulation monitoring function, automatically turns off the
output to ensure safe charging when insulation level is low.
16. High efficiency, high reliability, ultralow radiation, fast
maintenance, flexible capacity expansion, energy efficiency and
environmental protection
17. High adaptability of temperature range, has isolated heat
dissipation air ducts. Power heat dispassion is separated from
control circuit to ensure dust-free of control circuit.
18. Metal closed shell, to prevent from fire.
19. Have display interface which can be customized
After-sale Service
1. Two years warranty for all parts. If any parts break during the
period, we will provide free replacement.
Non-quality factor damage is not included.
2. One to one technical engineer support for
installation&operation and communication connection assistance
between your app and our OCPP platform.
Additional Accessories for Options
1. Pestle.
2. Wifi connection to Internet.
3. 3g/4g/GPRS connection to Internet.
4. Customized cable length.
5. Customized Box color and customized logo
